Crown FC 4010-50 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
6.77ft in
B
Overall Width
3.62ft in
C
Overall Height - Mast Lowered
6.92ft in
D
Wheelbase
4.15ft in
E
Ground Clearance
3in
F
Height To Top Of Overhead Guard
7.17ft in
G
Max Fork Height
15.67ft in
Right Angle Stack
7.31ft in
Turning Radius
6ft in
Mast
H
Mast Tip Forward
5degrees
I
Mast Tip Rear
5degrees
Max Fork Spread
36in
Lower Speed
84ft/min
Load Center
24in
Load Capacity
5000lb
Lift Speed
76ft/min
Specifications
Engine
Fuel Type
Electric 36/48 volts
Operational
Operating Weight
10720lb
Tire Type
cushion
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
8.8mph
