Daewoo DSL702 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.53ft in
B
Width Over Tires
4.88ft in
E
Ground Clearance
7.49in
C
Height To Top Of Cab
6.42ft in
D
Wheelbase
3.53ft in
F
Length W/O Bucket
8.28ft in
G
Clearance At Max Lift And Dump
7.3ft in
H
Reach At Max Lift And Dump
25.4in
Turning Radius From Center - Machine Rear
63.27in
Turning Radius From Center - Inc Bucket
74.85in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2253
Engine Model
D427
Gross Power
51hp
Power Measured @
2400rpm
Displacement
164.8cu in
Operational
Operational Weight
6095.8lb
Fuel Capacity
14.3gal
Max Speed
6.8mph
Tire Size
10 x 16.5
Loader
Breakout Force
3284.9lb
Operating Load Rating
1499.2lb
Tipping Angle
3946.3degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
15.9gal/min
