Doosan DX225LL-5 Log Loader
Units
Dimensions
Boom/Stick Option (Lgl) 1
A
Shipping Length
45.44ft in
C
Shipping Height
11.59ft in
I
Max Height
42.2ft in
J
Max Reach At Ground Level
35416.67ft in
K
Max Depth Below Ground
11.31ft in
Boom/Stick Option (Lgl) 1
Boom - 20 ft 2 in / Arm - 12 ft
Dimensions
B
Overall Width
11.82ft in
D
Length Of Track On Ground
45.44ft in
E
Ground Clearance
2.38ft in
H
Tail Swing Radius
10.36ft in
G
Height To Top Of Cab
15.16ft in
Undercarriage
Rollers And Idlers
2
Ground Pressure
8psi
Counterweight, Standard
9700.34lb
Specifications
Engine
Starter
8.1hp
Battery
150 AH
Number Of Cylinders
6
Gross Horsepower
166.3hp
Engine Make
Doosan
Engine Model
DL06P
Net Power
162.3hp
Air Cleaner
Double Elements
Net Torque
557lb ft
Displacement
359cu in
Bore
4in
Stroke
5in
Alternator
80amps
Operational
Def Tank Capacity
8.4gal
Operating Weight
68784.3lb
Fuel Capacity
265.8gal
Cooling System Fluid Capacity
8gal
Engine Oil Capacity
7.2gal
Hydraulic System Fluid Capacity
74gal
Swing Drive Fluid Capacity
1.4gal
Swing Mechanism
Swing Speed
10.2rpm
Swing Torque
69623lb ft
Hydraulic
Pump Flow Capacity
112.8gal/min
Relief Valve Pressure
4694psi
