Doosan S175LCV Midi Excavator
Dimensions
Boom/Stick Option (Hex) 1
Max Cutting Height
28.09ft in
Max Loading Height
19.17ft in
Max Reach Along Ground
27.89ft in
Max Vertical Wall Digging Depth
15.52ft in
Max Digging Depth
19.1ft in
Boom/Stick Option (Hex) 1
Boom 16'11" (5150mm)/Stick 7'3" (2200mm)
Boom/Stick Option (Hex) 2
Max Cutting Height
28.94ft in
Max Loading Height
19.95ft in
Max Reach Along Ground
29.2ft in
Max Digging Depth
20.41ft in
Max Vertical Wall Digging Depth
17.16ft in
Boom/Stick Option (Hex) 2
Boom 16'11" (5150mm)/Stick 8'6" (2600mm)
Boom/Stick Option (Hex) 3
Max Cutting Height
29.5ft in
Max Loading Height
20.51ft in
Max Reach Along Ground
30.68ft in
Max Vertical Wall Digging Depth
18.71ft in
Max Digging Depth
22.05ft in
Boom/Stick Option (Hex) 3
Boom 16'11" (5150mm)/Stick 10'2" (3100mm)
Boom/Stick Option (Hex) 4
Max Cutting Height
31.57ft in
Max Loading Height
22.31ft in
Max Reach Along Ground
30.06ft in
Max Digging Depth
20.38ft in
Max Vertical Wall Dig Depth
17.43ft in
Boom/Stick Option (Hex) 4
Boom 18'4" (5600mm)/Stick 7'3" (2200mm)
Boom/Stick Option (Hex) 5
Max Cutting Height
30.52ft in
Max Loading Height
21.3ft in
Max Reach Along Ground
28.71ft in
Max Digging Depth
19.03ft in
Max Vertical Wall Dig Depth
15.95ft in
Boom/Stick Option (Hex) 5
Boom 18'4" (5600mm)/Stick 8'6" (2600mm)
Boom/Stick Option (Hex) 6
Max Cutting Height
32.39ft in
Max Loading Height
23.13ft in
Max Reach Along Ground
31.57ft in
Max Digging Depth
21.99ft in
Boom/Stick Option (Hex) 6
Boom 18'4" (5600mm)/Stick 10'2" (3100mm)
Max Vertical Wall Dig Depth
19ft in
Dimensions
Width To Outside Of Tracks
9.19ft in
Length Of Track On Ground
10.6ft in
Ground Clearance
1.51ft in
Height To Top Of Cab
9.62ft in
Tail Swing Radius
8.04ft in
Removal Counterweight Clearance
3.42ft in
Undercarriage
Shoe Size
23.63in
Number Of Shoes Per Side
49
Ground Pressure
5.8psi
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.1mph
Number Of Track Rollers Per Side
8
Specifications
Engine
Number Of Cylinders
6
Engine Make
2252
Engine Model
DB58TIS
Net Power
118hp
Power Measured @
1950rpm
Displacement
353cu in
Max Torque
332.7lb ft
Torque Measured @
1450rpm
Aspiration
turbocharged air-to-water intercooled
Operational
Operating Weight
17400lb
Fuel Capacity
74gal
Cooling System Fluid Capacity
5.9gal
Operating Voltage
24V
Hydraulic System Fluid Capacity
55.5gal
Engine Oil Capacity
5.1gal
Swing Drive Fluid Capacity
1.4gal
Hydraulic System Relief Valve Pressure
4690psi
Hydraulic Pump Flow Capacity
80.4gal/min
Swing Mechanism
Swing Speed
11.7rpm
Buckets
Reference Bucket Capacity
0.8yd3
Minimum Bucket Capacity
0.5yd3
Maximum Bucket Capacity
1.3yd3
