Dressta RD165C Motor Grader
Units
Dimensions
Dimensions
A
Overall Length
28.55ft in
B
Width Over Tires
8.37ft in
D
Wheelbase
20.84ft in
G
Tandem Axle Wheelbase
4.92ft in
H
Blade Base
8.54ft in
Height To Top Of Isomount Cab
11.49ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
QSB 6.7
Power Measured @
2500rpm
Net Power Gear 5-6
160hp
Torque Measured @
1500rpm
Max Power
160hp
Net Torque Gears 5-6
590.1lb ft
Displacement
408.9cu in
Aspiration
turbocharged and CAC
Operational
Hydraulic System Fluid Capacity
31gal
Std Operation Weight - Total
31526.2lb
Fuel Capacity
85.9gal
Cooling System Fluid Capacity
10.6gal
Transmission Fluid Capacity
9.3gal
Rear Diff/Final Drive Fluid Capacity
9.3gal
Tandem Case Fluid Capacity (Each)
6.7gal
Tire Size
16.9-24 IND TI04 12PR
Operating Voltage
24V
Alternator Supplied Amperage
75amps
Steering
Articulation Angle
27degrees
Turning Radius
23ft in
Transmission
Transmission Type
powershift transmission
Number Of Gears - Forward
6
Number Of Gears - Reverse
3
Max Speed - Forward
24.9mph
Max Speed - Reverse
16.8mph
Front Axle
Wheel Lean
22degrees
Oscillation - Total
40degrees
Ground Clearance
2ft in
Moldboard
Moldboard Width
12ft in
Moldboard Height
25.6in
Moldboard Thickness
0.7in
Max Depth Of Cut
13.8in
Side Shift Left
31.5in
Side Shift Right
31.5in
Hydraulic System
Pump Type
axial piston pump
Pump Flow
16.3gal/min
Relief Valve Pressure
2030.6psi
Circle
Diameter
53.2in
Rotation
360degrees
Max Lift Above Ground
19.7in
