Dressta TD7M LT Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
15.69ft in
C
Height To Top Of Cab
8.73ft in
E
Ground Clearance
1.06ft in
Undercarriage
H
Standard Shoe Size
15in
Ground Contact Area
2460in2
Number Of Track Rollers Per Side
6
Track Pitch
6.5in
Number Of Shoes Per Side
37
Ground Pressure
6.86psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2347
Engine Model
B4.5
Gross Power
80hp
Net Power
74hp
Power Measured @
2500rpm
Displacement
275cu in
Torque Measured @
1300rpm
Aspiration
4-cycle diesel, naturally aspirated, direct start, direct injection
Operational
Operating Weight
16970lb
Fuel Capacity
45gal
Cooling System Fluid Capacity
6.6gal
Hydraulic Fluid Capacity
18.5gal
Powertrain Fluid Capacity
18.5gal
Final Drives Fluid Capacity
2.5gal
Operating Voltage
12V
Transmission
Transmission Type
Modular countershaft type full power shift, eletro-hydraulically
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
5.7mph
Max Speed - Reverse
6.7mph
Hydraulic System
Pump Type
Pump. tandem gear
Relief Valve Pressure
2250psi
Pump Flow Capacity
19.9gal/min
Standard Blade
Width
8.6ft in
Height
2.8in
Capacity
1.9yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
11in
