Dynapac CC1100C VI Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
94in
B
Overall Width
4.42ft in
C
Height To Top Of Cab
8.34ft in
D
Wheelbase
67in
E
Ground Clearance
7in
Gradeability
71%
Overhang Front
0.25ft in
Overhang Rear
0.25ft in
Turning Radius - Inside
9ft in
Turning Radius - Outside
12ft in
Curb Clearance
22in
Specifications
Engine
Emissions Certification
Tier 4i
Engine Make
Kubota
Engine Model
D1703-M IIIA
Engine Type
Water cooled
Gross Power
35hp
Power Measured @
2800rpm
Operational
Operating Weight Rops
4900lb
Oscillating Angle
10degrees
Operating Weight
6600lb
Fuel Capacity
12gal
Engine Oil Capacity
5.3gal
Water Spray System Fluid Capacity
49gal
Max Speed
6.3mph
Steering Angle
30degrees
Drum
Drum Thickness
0.5in
Drum Width
42in
Drum Diameter
28in
Static Linear Load
60lb/in
Vibration Frequency 1
66Hz
Nominal Amplitude - High
0.1in
Vibration Frequency 2
61Hz
Centrifugal Force - High
6519.5lb
Centrifugal Force - Low
5620.3lb
Brakes
Parking Brake
Failsafe multidisc brake on drum and wheels
Service Brake
Hydrostatic in forward and reverse lever
