Dynapac CC1250 Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
97.92in
B
Overall Width
4.15ft in
D
Wheelbase
71.3in
E
Ground Clearance
7.21in
Turning Radius - Inside
9.52ft in
Turning Radius - Outside
13.46ft in
Overhang Front
0.11ft in
Gradeability
38%
Curb Clearance
22.54in
Overhang Rear
0.11ft in
Specifications
Engine
Engine Make
Kubota
Engine Model
D1703-M
Gross Power
35hp
Power Measured @
2800rpm
Operational
Operating Weight Rops
6613.9lb
Oscillating Angle
10degrees
Operating Weight
6834.4lb
Fuel Capacity
13.3gal
Water Spray Tank Fluid Capacity
42.3gal
Steering Angle
29degrees
Drum
Drum Thickness
0.6in
Drum Width
47.3in
Drum Diameter
26.9in
Static Linear Load
74.5lb/in
Vibration Frequency 1
58Hz
Nominal Amplitude - High
0.1in
Centrifugal Force - High
6069.9lb
