Dynapac SD1800C Asphalt Paver
Units
Dimensions
Dimensions
C
Transport Height
9.59ft in
D
Wheelbase
6.86ft in
Overall Length
197.64in
Track Width
10.24in
Height
141.74in
Working Width- Maximum,
15.42ft in
Working Width- Minimum
2.3ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
Deutz
Gross Power
72.5hp
Power Measured @
2200rpm
Displacement
177cu in
Operational
Operational Weight
21000lb
Fuel Capacity
19.3gal
Operating Voltage
24V
Hopper/Paver
Hopper Capacity
21000lb
Paving Width - Std
6ft in
Hopper Length
2in
Paving Width - Max
10ft in
Paving Thickness - Max
7.9in
Paving Speed - Max
82.1ft/min
Travel Speed - Max
2.5mph
Auger Diameter
12.6in
Conveyor Width
27.6in
Undercarriage
Crawler Length
82.3in
Crawler Width
10.3in
