EP CPCD70 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
11.82ft in
B
Overall Width
6.53ft in
C
Overall Height - Mast Lowered
8.21ft in
D
Wheelbase
7.39ft in
E
Ground Clearance
6.7in
F
Height To Top Of Overhead Guard
7.49ft in
G
Max Fork Height
14.51ft in
Right Angle Stack
12.78ft in
Turning Radius
10.5ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
12degrees
Load Capacity
15432.36lb
Max Fork Spread
60.24in
Load Center
23.63in
Lift Speed
_-
Specifications
Engine
Engine Make
2353
Engine Model
6BG1QP
Power
113.5hp
Torque
303.2lb ft
Displacement
396.3cu in
Fuel Type
diesel
Operational
Operating Weight
20503lb
Tire Type
front 8.25-15-14PR rear 8.25-15-14PR
Max Speed
15mph
