Fendt 815 4WD Tractor

4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
4WD Tractor
Units

Dimensions

Dimensions

A

Overall Length

15.42in

B

Width Outside Frame

8.37ft in

C

Height To Top Of Cab

9.91ft in

D

Wheelbase

8.93in

E

Ground Clearance

22.45in

Tire Size

Front 480/70R30, Rear 580/70R42


Specifications

Engine

Number Of Cylinders

6

Engine Make

0

Net Power

147.6hp

Gross Power

166.3hp

Power Measured @

2100rpm

Displacement

348cu in

Torque Rise

37%

Aspiration

Turbocharger and intercooler

Operational

Operating Weight

14660.8lb

Fuel Capacity

89.9gal

Hydraulic System Fluid Capacity

11.9gal

Turning Radius

18.4ft in

Operating Voltage

12V

Alternator Supplied Amperage

150amps

Transmission

Transmission Type

stepless Vario transmission

Max Speed

31.1mph

Hydraulic System

Pump Flow Capacity

29.1gal/min

Relief Valve Pressure

2900.8psi


Compare similar models

Manufacturer/Model

Gross Power

Operating Weight

Gross Power

162.3 hp

Operating Weight

14561.6 lb

Gross Power

165 hp

Operating Weight

14054.5 lb

Gross Power

177.1 hp

Operating Weight

14660.8 lb
