Fendt 822 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
207.64in
D
Wheelbase
114.18in
E
Ground Clearance
20.2in
Track Width Front
6.57ft in
Track Width Rear
6.47ft in
Turning Radius
18ft in
Specifications
Engine
Number Of Cylinders
6
Gross Power
200hp
Pto Power
185hp
Power Measured @
2100rpm
Displacement
370cu in
Torque Measured @
1900rpm
Bore
4in
Stroke
5in
Operational
Fuel Capacity
133.5gal
Operating Weight
20503lb
Drawbar Static Vertical Load Rating
18300lb
3 Point Hitch Lift Capacity @ 24 Inches
11307lb
Alternator Supplied Amperage
150amps
Operating Voltage
12V
Transmission
Transmission Type
Continuously variable Vario transmission
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed
31.1mph
Hydraulic System
Pump Flow Capacity
29gal/min
