Fendt IDEAL 7 Combine
Units
Specifications
Residue Management
Basecut Configuration - Knives
56
Basecut Configuration - Rows
4
Shortcut Configuration - Rows
8
Shortcut Configuration - Knives
112
Straw Chopper Speed - Low
850rpm
Straw Chopper Speed - High
3600rpm
Engine
Emission Tier Level
Tier 4F
Engine Model
AGCO Power
Power
451hp
Power Measured @
1900rpm
Displacement
598.1cu in
Operational
Max Speed
25mph
Transmission Type
2 Speed Motion Shift
Feeding
Feederhouse Lifting Capacity
10000lb
Feeder Description
3 Strand
Threshing
Rotor Feeder Length
24in
Rotor Width
190.5in
Rotor Feeder Width
55in
Rotor Type
Single
Threshing Area
1287in2
Rotor Length
24in
Rotor Speed - Low
285rpm
Rotor Speed - High
656rpm
Separating
Separating Area
2232in2
Discharge Grate Area
3519in2
Cleaning System
Total Sieve Area-Fixed
7595in2
Total Cleaning Area
11548in2
Cleaning Fan Speed - Low
250rpm
Cleaning Fan Speed - High
1400rpm
Cleaning Fan Description
3 x Impeller Fan
Grain Handling
Grain Tank Capacity
350bu
Unloading Speed
4bu/sec
