Ford 7610 MFWD Tractor
Units
Dimensions
Dimensions
A
Overall Length
144.89in
D
Wheelbase
7.29ft in
B
Overall Width
5.71ft in
E
Ground Clearance
18.12in
Height With Rops
7.98ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
Ford
Gross Power
97hp
Pto Power
86hp
Power Measured @
2100rpm
Max Torque
278.1lb ft
Displacement
268.6cu in
Bore
4.5in
Stroke
4.5in
Operational
Operating Weight
5934.9lb
Fuel Capacity
34.5gal
Hydraulic System Fluid Capacity
15gal
3 Point Hitch Lift Capacity @ 24 Inches
4471lb
Operating Voltage
12V
Alternator Supplied Amperage
51amps
Transmission
Number Of Forward Gears
8
Number Of Reverse Gears
2
Hydraulic System
Hydraulic System Type
Open
Maximum System Pressure
2500psi
Pump Flow Capacity
18.2gal/min
Number Of Remote Control Valves
1
