Gehl 3635 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
9.51ft in
B
Width Over Tires
4.03ft in
E
Ground Clearance
5.99in
C
Height To Top Of Cab
5.86ft in
D
Wheelbase
2.87ft in
F
Length W/O Bucket
7.34ft in
G
Clearance At Max Lift And Dump
7.05ft in
H
Reach At Max Lift And Dump
22.76in
Turning Radius From Center - Machine Rear
26.46in
Turning Radius From Center - Inc Bucket
34.36in
Specifications
Engine
Engine Make
2348
Engine Model
3TNE88 diesel
Net Power
36hp
Power Measured @
3000rpm
Displacement
100cu in
Operational
Operational Weight
4400lb
Fuel Capacity
8.6gal
Hydraulic System Fluid Capacity
8.1gal
Max Speed
6.9mph
Tire Size
8.50x15
Operating Voltage
12V
Alternator Supplied Amperage
40amps
Loader
Operating Load Rating
1050lb
Hydraulic
Pump Flow Capacity
14.4gal/min
