Gehl 803 Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
21.56ft in
I
Max Cutting Height
22.91ft in
J
Max Loading Height
15.88ft in
K
Max Reach Along Ground
23.53ft in
L
Max Vertical Wall Digging Depth
12.05ft in
M
Max Digging Depth
14.08ft in
Boom/Stick Option (Hex) 1
Standard arm 6'1" (1850mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
23.53ft in
J
Max Loading Height
16.51ft in
K
Max Reach Along Ground
24.41ft in
M
Max Digging Depth
15.03ft in
L
Max Vertical Wall Digging Depth
13.03ft in
Boom/Stick Option (Hex) 2
Long arm 7'1" (2150mm)
Dimensions
D
Length Of Track On Ground
7.34ft in
E
Ground Clearance
0.96ft in
G
Height To Top Of Cab
8.9ft in
H
Tail Swing Radius
5.09ft in
Undercarriage
N
Shoe Size
17.72in
Max Travel Speed
3.2mph
Number Of Track Rollers Per Side
5
Ground Pressure
5.1psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2291
Engine Model
Yanmar 4TNV98-VNS, A TIER II
Gross Power
69hp
Net Power
57hp
Power Measured @
2100rpm
Displacement
202cu in
Operational
Operating Weight
17548lb
Fuel Capacity
24.6gal
Operating Voltage
12V
Hydraulic System Fluid Capacity
26.2gal
Alternator Supplied Amperage
88amps
Hydraulic System Relief Valve Pressure
4351psi
Hydraulic Pump Flow Capacity
63gal/min
Swing Mechanism
Swing Speed
9.2rpm
Buckets
Reference Bucket Capacity
0.3yd3
Minimum Bucket Capacity
0.2yd3
Maximum Bucket Capacity
0.5yd3
