Gehl CTL70 Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.81ft in
C
Height To Top Of Cab
7.11ft in
E
Ground Clearance
12.8in
G
Clearance At Max Lift And Dump
7.91ft in
H
Reach At Max Lift And Dump
2.87ft in
Turning Radius From Center - Inc Bucket
90.32in
Length With Bucket
12.17ft in
Length With Out Bucket
9.68ft in
Turning Radius From Center - Machine Rear
65.6in
Undercarriage
D
Length Of Track On Ground
4.91ft in
Number Of Track Rollers Per Side
4
Width Of Track
18in
Ground Pressure
4.1psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2353
Engine Model
4JG1T
Net Power
81hp
Power Measured @
2400rpm
Peak Torque
190lb ft
Torque Measured @
1800rpm
Displacement
187cu in
Aspiration
turbocharged
Operational
Operating Weight
9590lb
Cooling System Fluid Capacity
4gal
Fuel Capacity
23.9gal
Engine Oil Capacity
2.5gal
Hydraulic System Fluid Capacity
13.7gal
Operating Voltage
12V
Alternator Supplied Amperage
50amps
Max Speed - Low Range
4.5mph
Max Speed - High Range
6.5mph
Loader
Breakout Force
7401lb
Operating Load
2976lb
Tipping Angle
5952degrees
Hydraulic
Pump Flow
19.8gal/min
Relief Valve Pressure
2988psi
