Genie GS3268DC Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
8.76in
D
Wheelbase
6.07ft in
B
Overall Width
5.68ft in
C
Height W/ Rails
8.04ft in
E
Ground Clearance
7.49in
Height W/O Rails
6.01ft in
Turning Radius
12.08ft in
Platform
F
Max Platform Height
31.99ft in
I
Deck Extension
59.85in
Max Working Height
38.55ft in
Max Platform Weight Capacity
1000.9lb
Platform Inner Length
98.82in
Platform Inner Width
61.03in
Lower Time
37sec
Lift Time
50sec
Specifications
Engine
System Voltage
24V
Number Of Batteries
4
Operational
Operating Weight
8009.4lb
Hydraulic System Fluid Capacity
9.6gal
Max Speed
3mph
Tire Size
12.5x22
Tire Fill/Type
Solid non-marking
