Goldoni Star 3060 LE Low 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
11.34in
B
Width Outside Frame
4.24ft in
C
Height To Top Of Cab
6.76ft in
D
Wheelbase
5.55in
E
Ground Clearance
8.67in
Tire Size
front 11.0/65x12, rear 320-85x20
Specifications
Engine
Number Of Cylinders
3
Engine Make
2393
Net Power
57.7hp
Power Measured @
2600rpm
Displacement
127.1cu in
Torque Rise
15%
Aspiration
Turbocharged
Operational
Fuel Capacity
13.3gal
Operating Weight
4497.5lb
Turning Radius
9.9ft in
Transmission
Transmission Type
40 speeds, a liver can be used to select the 8+8 transmission with synchronized reverse shuttle or the 16+8 transmission with synchronized Dual power
Max Speed
18.7mph
Hydraulic System
Pump Flow Capacity
10.1gal/min
Number Of Remote Control Valves
1
