Goldoni Star 3070 Vineyard 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
10.56in
B
Width Outside Frame
5.81ft in
C
Height To Top Of Cab
6.67ft in
D
Wheelbase
5.94in
Tire Size
rear: 320/70x24, front: 240/70x16
Specifications
Engine
Number Of Cylinders
4
Engine Make
2393
Net Power
68hp
Power Measured @
2600rpm
Displacement
181.3cu in
Operational
3 Point Hitch Type
Cat I and II
3 Point Hitch Lift Capacity @ 24 Inches
5070.7lb
Transmission
Transmission Type
40 speeds, a lever can be used to select the 8+8 transmission with synchronized reverse shuttle or the 16+8 transmission with synchronized dual power
Number Of Forward Gears
24
Number Of Reverse Gears
16
Hydraulic System
Pump Flow Capacity
10.1gal/min
