Grove AMZ40BXT Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
13.85in
B
Overall Width
6.5ft in
C
Overall Height - Mast Lowered
6.67ft in
D
Wheelbase
6.99ft in
E
Ground Clearance
8.27in
Turning Radius
9.36ft in
Platform
F
Max Platform Height
34.13ft in
G
Max Horizontal Reach
20.02ft in
Platform Inner Length
48.04in
Max Platform Weight Capacity
500.45lb
Max Working Height
40.03ft in
Platform Inner Width
29.93in
Specifications
Engine
Engine Make
2355
Engine Model
M20S
Gross Power
20hp
Fuel Type
Gasoline
Operational
Operating Weight
9901lb
Fuel Capacity
8.5gal
Hydraulic System Fluid Capacity
14.1gal
Max Speed
2.5mph
Tire Size
8x16.5 Rib
Tire Fill/Type
Air
