Grove GMK5200-1 All Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
52.5ft in
J
Max Height @ Max Raise Angle - No Jib
216.54ft in
M
Max Elevating Angle
82degrees
Number Of Sections
6
Max Lift Capacity
479999.95lb
Dimensions
A
Transport Length
54.73ft in
B
Transport Width
8.9ft in
C
Transport Height
12.96ft in
E
Ground Clearance
1.6ft in
F
Width W/ Outriggers Extended
25.6ft in
G
Carrier Length
44.8ft in
H
Upper Structure Tail Swing Radius
17.39ft in
Specifications
Carrier Engine
Make
Grove
Model
OM471LA
Gross Power
523hp
Power Measured @
1700rpm
Max Torque
1814.5lb ft
Torque Measured @
1300rpm
Number Of Cylinders
6
Aspiration
Turbocharged
Emission Level
Euromot 4 / EPA / CARB Tier 4 final
Operational
Operating Weight
146938.1lb
Number Of Axels
5
Carrier Fuel Capacity
171.8gal
Upper Structure Hydraulic System Fluid Capacity
235.2gal
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Tire Size
385/95 R25
Transmission
Transmission Type
Mercedes G 280 with VIAB
Number Of Forward Gears
16
Number Of Reverse Gears
2
