Grove GMK5275 European Version All Terrain Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
50ft in
J
Max Height @ Max Raise Angle - No Jib
232.94ft in
K
Min Working Radius
8ft in
L
Max Working Radius
200ft in
M
Max Elevating Angle
83degrees
Number Of Sections
7
Max Lift Capacity
550000lb
Swing Speed
1.3rpm
Dimensions
A
Transport Length
50.61ft in
C
Transport Height
13.05ft in
F
Width W/ Outriggers Extended
26.25ft in
G
Carrier Length
43.94ft in
H
Upper Structure Tail Swing Radius
14.46ft in
Specifications
Upper Structure Engine
Make
Grove
Model
OM 906 LA
Gross Power
228hp
Power Measured @
2200rpm
Max Torque
597.5lb ft
Torque Measured @
1200rpm
Carrier Engine
Make
Grove
Model
OM 502 LA
Gross Power
563.3hp
Power Measured @
1800rpm
Max Torque
1991.5lb ft
Torque Measured @
1200rpm
Operational
Operating Weight
128165.8lb
Number Of Axels
5
Carrier Fuel Capacity
136.1gal
Upper Structure Hydraulic System Fluid Capacity
241.8gal
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Tire Size
16.00R25
Transmission
Transmission Type
Allison
Number Of Forward Gears
6
Number Of Reverse Gears
1
Max Speed - Forward
52.9mph
