Grove IND68 Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
13ft in
J
Max Height @ Max Raise Angle - No Jib
21ft in
K
Min Working Radius
6ft in
L
Max Working Radius
19ft in
M
Max Elevating Angle
70degrees
Max Lift Capacity
20000lb
Swing Speed
3.25rpm
Number Of Sections
2
Dimensions
A
Transport Length
25.69ft in
B
Transport Width
8.07ft in
C
Transport Height
9.81ft in
E
Ground Clearance
0.9ft in
F
Width W/ Outriggers Extended
13.92ft in
G
Carrier Length
16.71ft in
Specifications
Carrier Engine
Make
Grove
Model
300
Net Power
115hp
Power Measured @
2800rpm
Max Torque
216lb ft
Torque Measured @
2800rpm
Displacement
300cu in
Operational
Operating Weight
35500lb
Number Of Axels
2
Carrier Fuel Capacity
43.1gal
Carrier Hydraulic System Fluid Capacity
46gal
Carrier Cooling System Fluid Capacity
6.4gal
Operating Voltage
12V
Alternator Supplied Amperage
38amps
Tire Size
(R)10x15-14PLY (F)11X2014PLY
Transmission
Transmission Type
powershift
Number Of Forward Gears
4
Number Of Reverse Gears
4
Max Speed - Forward
25mph
