Grove SM3146E Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
8.24in
D
Wheelbase
6.04ft in
B
Overall Width
3.84ft in
C
Height W/ Rails
8.17ft in
E
Ground Clearance
3.94in
Height W/O Rails
6.5ft in
Turning Radius
11.16ft in
Platform
F
Max Platform Height
24.94ft in
I
Deck Extension
35.83in
J
Height Of Rails
3.52ft in
Max Platform Weight Capacity
848.78lb
Lower Time
34sec
Max Working Height
31.17ft in
Platform Inner Width
42.13in
Lift Time
32sec
Platform Inner Length
92.13in
Specifications
Engine
System Voltage
24V
Number Of Batteries
4
Battery Amp Hours
250
Charger Amps
25amps
Operational
Operating Weight
4221.9lb
Max Speed
2.5mph
Tire Size
16x5
Tire Fill/Type
Solid
