Grove TM550 Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
33ft in
J
Max Height @ Max Raise Angle - No Jib
105ft in
K
Min Working Radius
12ft in
L
Max Working Radius
100ft in
M
Max Elevating Angle
75degrees
Number Of Sections
4
Max Lift Capacity
110000lb
Swing Speed
2.5rpm
Dimensions
A
Transport Length
38.67ft in
B
Transport Width
10.17ft in
C
Transport Height
13.35ft in
F
Width W/ Outriggers Extended
20ft in
G
Carrier Length
31.59ft in
Specifications
Upper Structure Engine
Number Of Cylinders
6
Make
Grove
Model
6V-53
Gross Power
195hp
Power Measured @
2800rpm
Max Torque
423lb ft
Torque Measured @
1500rpm
Carrier Engine
Make
Grove
Model
6-7IN
Gross Power
252hp
Power Measured @
2300rpm
Max Torque
604lb ft
Torque Measured @
1200rpm
Displacement
425.6cu in
Number Of Cylinders
6
Operational
Operating Weight
101000lb
Number Of Axels
4
Upper Structure Fuel Capacity
75gal
Carrier Fuel Capacity
60gal
Upper Structure Hydraulic System Fluid Capacity
200gal
Operating Voltage
12V
Alternator Supplied Amperage
60amps
Tire Size
14.00x20,18ply
Transmission
Transmission Type
Fuller
Number Of Forward Gears
5
Number Of Reverse Gears
1
Max Speed - Forward
37.5mph
Max Speed - Reverse
5mph
