Grove YB4408 Hydraulic Truck Crane
Units
Dimensions
Boom
I
Min Height @ Max Raise Angle
10.9ft in
J
Max Height @ Max Raise Angle - No Jib
24ft in
K
Min Working Radius
5ft in
L
Max Working Radius
22ft in
M
Max Elevating Angle
70degrees
Max Lift Capacity
17000lb
Swing Speed
1.5rpm
Number Of Sections
3
Dimensions
A
Transport Length
15.8ft in
B
Transport Width
7.01ft in
C
Transport Height
7.75ft in
E
Ground Clearance
0.67ft in
F
Width W/ Outriggers Extended
10.84ft in
G
Carrier Length
14.09ft in
H
Upper Structure Tail Swing Radius
3.53ft in
Specifications
Upper Structure Engine
Make
Grove
Carrier Engine
Make
Grove
Model
TM 2.7L
Gross Power
62hp
Power Measured @
2800rpm
Max Torque
135.8lb ft
Torque Measured @
1800rpm
Operational
Operating Weight
16500lb
Number Of Axels
2
Carrier Fuel Capacity
30.2gal
Upper Structure Hydraulic System Fluid Capacity
30.2gal
Operating Voltage
12V
Tire Size
10.00 x 15-14PR
Transmission
Transmission Type
Automatic
Number Of Forward Gears
3
Number Of Reverse Gears
1
Max Speed - Forward
15mph
