Hamm 3412 HT VIO Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
224.61in
C
Height To Top Of Cab
9.81ft in
D
Wheelbase
118.71in
E
Ground Clearance
14.77in
Angle Of Driving Slope-Front
31degrees
Width Over Cab
88.59in
Angle Of Driving Slope-Rear
34degrees
Loadover Height
7.63ft in
Turning Radius - Inside
12.11ft in
Specifications
Steering System
Steering Method
Articulated steering
Oscillating Angle
10degrees
Speeds
Speed - Working Gear
7mph
Speed - Transportation Gear
11mph
Size Of Tyres, Rear
AW 23.1-26 12 PR
Engine
Emissions Certification
EU Stage IIIA / EPA Tier 3
Engine Power@Iso 14396
134.2hp
Engine Power@Saej1349
134.2hp
Number Of Cylinders
4
Engine Make
Deutz
Engine Model
TCD 2012 L04 2V
Power Measured @
2300rpm
Operational
Operating Weight Cabin
26290.2lb
Operating Weight Rops
25805.2lb
Fuel Capacity
76.7gal
Max Weight
33664.6lb
Max Speed
14mph
Axle Load - Front
14782lb
Axle Load - Rear
12114.5lb
Drum
Oscillation Force - Front
51706.1lb
Oscillation Frequency - Front
30Hz
Tangential Amplitude - Front
0.1in
Drum Type
smooth
Drum Thickness
1.2in
Drum Width
84.3in
Drum Diameter
59.3in
Static Linear Load
168lb/in
Vibration Frequency 1
33Hz
Nominal Amplitude - High
0.1in
Centrifugal Force - High
62721.7lb
