Hamm 3516 HT Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
239.18in
C
Height To Top Of Cab
9.91ft in
D
Wheelbase
121.66in
E
Ground Clearance
14.77in
Angle Of Driving Slope-Front
31degrees
Width Over Cab
89.38in
Angle Of Driving Slope-Rear
27degrees
Loadover Height
7.52ft in
Turning Radius - Inside
14.31ft in
Specifications
Steering System
Steering Method
Articulated steering
Oscillating Angle
10degrees
Speeds
Size Of Tyres, Rear
AW 23.1-26 12 PR
Engine
Emissions Certification
EU Stage IIIA / EPA Tier 3
Engine Power@Iso 14396
207.9hp
Engine Power@Saej1349
207.9hp
Number Of Cylinders
4
Engine Make
Deutz
Engine Model
TCD 2012 L04 2V
Power Measured @
2300rpm
Operational
Operating Weight Cabin
34733.9lb
Operating Weight Rops
34248.9lb
Fuel Capacity
76.7gal
Max Weight
41469lb
Max Speed
14mph
Axle Load - Front
20514.1lb
Axle Load - Rear
14219.9lb
Drum
Drum Type
smooth
Drum Thickness
1.2in
Drum Width
84.3in
Drum Diameter
59.3in
Static Linear Load
435lb/in
Vibration Frequency 1
30Hz
Nominal Amplitude - High
0.1in
Vibration Frequency 2
40Hz
Nominal Amplitude - Low
0.1in
Centrifugal Force - High
57551.1lb
Centrifugal Force - Low
48334lb
