Haulotte H14TX Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
24.94in
B
Overall Width
7.55ft in
C
Overall Height - Mast Lowered
7.26ft in
D
Wheelbase
6.57ft in
E
Ground Clearance
13.78in
Turning Radius
15.75ft in
Platform
F
Max Platform Height
39.6ft in
G
Max Horizontal Reach
34.78ft in
Platform Rotation
180degrees
Platform Inner Length
90.56in
Max Platform Weight Capacity
507.07lb
Max Working Height
46.17ft in
Platform Inner Width
31.5in
Specifications
Engine
Engine Make
2349
Gross Power
41.6hp
Fuel Type
Diesel
Operational
Operating Weight
13316lb
Fuel Capacity
39.7gal
Hydraulic System Fluid Capacity
39.7gal
Max Speed
3.8mph
Tire Size
14-17.5
Tire Fill/Type
foam filled/Sks Hauler
