Hitachi EX400LC-5 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
38.69ft in
C
Shipping Height Of Unit
11.42ft in
I
Max Cutting Height
33.7ft in
J
Max Loading Height
23.1ft in
K
Max Reach Along Ground
36.72ft in
L
Max Vertical Wall Digging Depth
15.69ft in
M
Max Digging Depth
23.96ft in
Boom/Stick Option (Hex) 1
Boom 23\'0\" (7000mm) / Stick 9\'6\" (2900mm)
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
38.69ft in
I
Max Cutting Height
36.36ft in
C
Shipping Height Of Unit
11.42ft in
J
Max Loading Height
25.14ft in
K
Max Reach Along Ground
38.75ft in
L
Max Vertical Wall Digging Depth
21.86ft in
M
Max Digging Depth
25.46ft in
Boom/Stick Option (Hex) 2
Boom 23\'0\" (7000mm) / Stick 11\'2\" (3400mm)
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
38.69ft in
I
Max Cutting Height
36.68ft in
J
Max Loading Height
25.53ft in
C
Shipping Height Of Unit
11.42ft in
K
Max Reach Along Ground
40.26ft in
L
Max Vertical Wall Digging Depth
23.1ft in
M
Max Digging Depth
27.1ft in
Boom/Stick Option (Hex) 3
Boom 23\'0\" (7000mm) / Stick 12\'10\" (3900mm)
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
38.69ft in
C
Shipping Height Of Unit
11.42ft in
I
Max Cutting Height
38.88ft in
J
Max Loading Height
28.78ft in
K
Max Reach Along Ground
43.25ft in
M
Max Digging Depth
29.89ft in
Max Vertical Wall Dig Depth
27.73ft in
Boom/Stick Option (Hex) 4
Boom 23\'0\" (7000mm) / Stick 16\'1\" (4900mm)
Dimensions
E
Ground Clearance
2.42ft in
G
Height To Top Of Cab
10.77ft in
B
Width To Outside Of Tracks
11.95ft in
D
Length Of Track On Ground
14.67ft in
H
Tail Swing Radius
11.39ft in
Removal Counterweight Clearance
4.43ft in
Undercarriage
F
Track Gauge
9.49ft in
N
Shoe Size
29.53in
Max Travel Speed
3.42mph
Number Of Carrier Rollers Per Side
3
Number Of Shoes Per Side
53
Ground Pressure
8.97psi
Number Of Track Rollers Per Side
9
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
A-6RB1TQA
Net Power
301hp
Power Measured @
2000rpm
Max Torque
907.3lb ft
Aspiration
Turbocharged
Displacement
838cu in
Torque Measured @
1400rpm
Operational
Operating Weight
100500lb
Fuel Capacity
159.9gal
Cooling System Fluid Capacity
11.9gal
Hydraulic System Fluid Capacity
137.4gal
Engine Oil Capacity
13.3gal
Swing Drive Fluid Capacity
2.2gal
Alternator Supplied Amperage
40amps
Hydraulic System Relief Valve Pressure
4980psi
Hydraulic Pump Flow Capacity
190.3gal/min
Swing Mechanism
Swing Speed
9rpm
Buckets
Reference Bucket Capacity
2.4yd3
Minimum Bucket Capacity
1.8yd3
Maximum Bucket Capacity
3yd3
