Hitachi LX150 Super Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
9.13ft in
Bucket Capacity - Heaped
3.8yd3
Bucket Capacity - Struck
3.21yd3
Breakout Force
37430.69lb
Dimensions
E
Ground Clearance
1.6ft in
A
Length With Bucket On Ground
26.12ft in
B
Width Over Tires
9.08ft in
C
Height To Top Of Cab
11.23ft in
D
Wheelbase
10.5ft in
F
Hinge Pin - Max Height
13.13ft in
H
Reach At Max Lift And Dump
3.94ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2240
Engine Model
6076A
Net Power
170hp
Power Measured @
2200rpm
Max Torque
580.5lb ft
Displacement
466cu in
Torque Measured @
1300rpm
Aspiration
Turbocharged
Operational
Operating Weight
35400lb
Fuel Capacity
75.1gal
Hydraulic System Fluid Capacity
30.4gal
Engine Oil Fluid Capacity
5.9gal
Cooling System Fluid Capacity
7.6gal
Transmission Fluid Capacity
3.7gal
Front Axle/Diff Fluid Capacity
6.1gal
Rear Axle/Diff Fluid Capacity
6.1gal
Static Tipping Weight
27230lb
Turning Radius
21.2ft in
Operating Voltage
12V
Alternator Supplied Amperage
95amps
Rear Axle Oscillation
26degrees
Tire Size
23.5x25
Transmission
Transmission Type
Power Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
21.5mph
Max Speed - Reverse
13.7mph
Hydraulic System
Relief Valve Setting
3000psi
Pump Flow Capacity
69.5gal/min
Raise Time
6.2sec
Dump Time
1.8sec
Lower Time
3.5sec
Pump Type
Gear
