Hitachi ZX27U-3 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
14.05ft in
I
Max Cutting Height
14.05ft in
C
Shipping Height Of Unit
8.21ft in
J
Max Loading Height
9.95ft in
K
Max Reach Along Ground
15.1ft in
M
Max Digging Depth
8.5ft in
Boom/Stick Option (Hex) 1
Boom 6\'10\" (2.1 m) / Stick 3\'10\" (1.17 m)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
14.28ft in
A
Shipping Length Of Unit
14.05ft in
J
Max Loading Height
10.24ft in
C
Shipping Height Of Unit
8.21ft in
K
Max Reach Along Ground
16.08ft in
M
Max Digging Depth
9.49ft in
Boom/Stick Option (Hex) 2
Boom 6\'10\" (2.1 m ) / Stick 4\'10\" (1.47 m )
Dimensions
B
Width To Outside Of Tracks
5.09ft in
D
Length Of Track On Ground
4.89ft in
E
Ground Clearance
1.05ft in
G
Height To Top Of Cab
8.21ft in
H
Tail Swing Radius
2.55ft in
Removal Counterweight Clearance
1.81ft in
Undercarriage
N
Shoe Size
11.82in
Ground Pressure
4.35psi
Max Travel Speed
2.8mph
Specifications
Engine
Engine Make
2348
Engine Model
3TNV88
Net Power
26.4hp
Power Measured @
2200rpm
Displacement
100cu in
Operational
Operating Weight
6730lb
Fuel Capacity
10.6gal
Cooling System Fluid Capacity
1.4gal
Hydraulic System Fluid Capacity
8.5gal
Engine Oil Capacity
2gal
Alternator Supplied Amperage
40amps
Hydraulic Pump Flow Capacity
16.4gal/min
Swing Mechanism
Swing Speed
9.1rpm
