Hitachi ZX330LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
36.39ft in
C
Shipping Height Of Unit
11.39ft in
I
Max Cutting Height
32.39ft in
J
Max Loading Height
22.41ft in
K
Max Reach Along Ground
34.03ft in
L
Max Vertical Wall Digging Depth
18.44ft in
M
Max Digging Depth
22.48ft in
Boom/Stick Option (Hex) 1
boom 6400 mm w/ stick 2660mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
36ft in
I
Max Cutting Height
33.57ft in
C
Shipping Height Of Unit
10.6ft in
J
Max Loading Height
23.4ft in
K
Max Reach Along Ground
35.77ft in
L
Max Vertical Wall Digging Depth
21.26ft in
M
Max Digging Depth
24.22ft in
Boom/Stick Option (Hex) 2
boom 6400mm w/ stick 3200mm
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
36.26ft in
I
Max Cutting Height
34.85ft in
J
Max Loading Height
24.61ft in
C
Shipping Height Of Unit
11.72ft in
K
Max Reach Along Ground
38.33ft in
L
Max Vertical Wall Digging Depth
24.18ft in
M
Max Digging Depth
26.84ft in
Boom/Stick Option (Hex) 3
boom 6400mm w/ stick 4000mm
Dimensions
E
Ground Clearance
1.65ft in
G
Height To Top Of Cab
10.24ft in
B
Width To Outside Of Tracks
11.13ft in
D
Length Of Track On Ground
12.24ft in
H
Tail Swing Radius
10.9ft in
Removal Counterweight Clearance
3.75ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
23.63in
Number Of Track Rollers Per Side
8
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.42mph
Ground Pressure
9.14psi
Number Of Shoes Per Side
45
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
AA-6HK1X
Net Power
247hp
Power Measured @
2000rpm
Max Torque
643.9lb ft
Displacement
475.4cu in
Aspiration
turbocharged, intercooled
Torque Measured @
1700rpm
Operational
Operating Weight
73500lb
Fuel Capacity
148gal
Cooling System Fluid Capacity
9.3gal
Hydraulic System Fluid Capacity
84.6gal
Operating Voltage
24V
Engine Oil Capacity
9.6gal
Swing Drive Fluid Capacity
4.4gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
5050psi
Hydraulic Pump Flow Capacity
153.3gal/min
Swing Mechanism
Swing Speed
11.8rpm
Buckets
Reference Bucket Capacity
1.9yd3
Minimum Bucket Capacity
1.2yd3
Maximum Bucket Capacity
2.2yd3
