Hitachi ZX400LCH Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
35.96ft in
C
Shipping Height Of Unit
11.13ft in
I
Max Cutting Height
34.26ft in
J
Max Loading Height
24.05ft in
K
Max Reach Along Ground
35.77ft in
L
Max Vertical Wall Digging Depth
22.22ft in
M
Max Digging Depth
23.99ft in
Boom/Stick Option (Hex) 1
Boom 6400mm/Stick 3200mm
Dimensions
E
Ground Clearance
1.84ft in
G
Height To Top Of Cab
11.13ft in
B
Width To Outside Of Tracks
10.47ft in
D
Length Of Track On Ground
13.29ft in
H
Tail Swing Radius
11.06ft in
Removal Counterweight Clearance
4.14ft in
Undercarriage
F
Track Gauge
8.5ft in
N
Shoe Size
23.63in
Number Of Shoes Per Side
49
Max Travel Speed
3.11mph
Number Of Track Rollers Per Side
8
Ground Pressure
10.59psi
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
AH-6HK1X
Net Power
271hp
Power Measured @
1900rpm
Max Torque
796.6lb ft
Aspiration
Turbocharged & Intercooled
Displacement
475.4cu in
Torque Measured @
1500rpm
Operational
Operating Weight
85980.3lb
Fuel Capacity
166.5gal
Cooling System Fluid Capacity
8.5gal
Hydraulic System Fluid Capacity
98.9gal
Engine Oil Capacity
10.9gal
Operating Voltage
24V
Swing Drive Fluid Capacity
4.5gal
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
152.2gal/min
Swing Mechanism
Swing Speed
10.7rpm
Buckets
Reference Bucket Capacity
2.1yd3
