Hitachi ZX75US-5 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
I
Max Cutting Height
24.97ft in
K
Max Reach Along Ground
22.18ft in
M
Max Digging Depth
15.13ft in
Arm Digging Force - Iso
6901.64lb
Boom/Stick Option (Hex) 1
Arm Length - 2.12 m (6 ft 11 in)
Bucket Digging Force - Iso
10476.1lb
Max Digging Reach
22.71ft in
Min.Front Swing Radius
7.12ft in
Boom/Stick Option (Hex) 2
Boom/Stick Option (Hex) 2
Arm Length - 2.96 m (9 ft 9 in)
Boom/Stick Option (Hex) 3
Boom/Stick Option (Hex) 3
Arm Length - 3.61 m (11 ft 10 in)
Dimensions
E
Ground Clearance
1.19ft in
H
Tail Swing Radius
4.24ft in
O
Counterweight Clearance
2.4ft in
Undercarriage Overall Length
9.59ft in
Length
2507.88in
Max. Height
105.91in
Cab Height
8.83ft in
Undercarriage
Drawbar Pull
14661lb
Max Travel Speed
3.11mph
Number Of Shoes Per Side
40
Specifications
Electrical System
Battery Capacity
450CCA
Alternator Rating
50 amp
Batteries
2 x 12 V
Work Lights
2 halogen
Cylinders
Bore (Boom)
4.6in
Stroke (Boom)
34.9in
Rod Diameter (Boom)
2.6in
Bore (Arm)
3.8in
Stroke (Arm)
35.5in
Rod Diameter (Arm)
2.4in
Bore (Bucket)
3.4in
Stroke (Bucket)
28.8in
Rod Diameter (Bucket)
2.2in
Engine
Emissions Level
EPA Final Tier 4 / EU Stage IV
Number Of Cylinders
4
Off-Level Capacity
70%
Engine Make
Yanmar
Engine Model
4TNV98C
Net Power
56.9hp
Cooling System
High efficiency direct-driven, suction-type fan
Power Measured @
2000rpm
Aspiration
Natural
Displacement
201.4cu in
Capacities
Engine Oil With Filter
3.3gal
Fuel Tank
31.8gal
Hydraulic Tank
14.8gal
Hydraulic System
27.3gal
Propel
0.4gal
Operational
Operating Weight
19244.2lb
Cooling System Fluid Capacity
2.6gal
Hydraulic System Relief Valve Pressure
566psi
Hydraulic Pump Flow Capacity
52.9gal/min
Swing Mechanism
Swing Speed
10.5rpm
Swing Torque
12243.6lb ft
Hydraulic System
Main Pump Type
3 variable-displacement axial-piston pumps
Implement - Operating Pressure
3771psi
Travel - Operating Pressure
4554psi
Swing - Operating Pressure
3655psi
