Hyster H450HDS Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
17.95ft in
B
Overall Width
9.59ft in
C
Overall Height - Mast Lowered
13.88ft in
D
Wheelbase
11.49ft in
E
Ground Clearance
14.73in
F
Height To Top Of Overhead Guard
11.07ft in
G
Max Fork Height
15.26ft in
Gradeability
34%
Right Angle Stack
30.34ft in
Turning Radius
16.17ft in
Mast
H
Mast Tip Forward
10degrees
I
Mast Tip Rear
12degrees
Load Center
35.99in
Lower Speed
98ft/min
Lift Speed
49ft/min
Load Capacity
45000lb
Max Fork Spread
106.78in
Specifications
Engine
Emission Tier Level
TIER 4F
Battery
900 CCA
Number Of Cylinders
6
Engine Make
Cummins
Engine Model
QSB 6.7L
Power
220hp
Torque
700lb ft
Power Measured @
2000rpm
Displacement
408.9cu in
Torque Measured @
1500rpm
Fuel Type
Diesel
Alternator
120amps
Operational
Def Tank Capacity
10gal
Operational Weight
61963lb
Tire Type
Pneumatic
Max Speed
16mph
Operating Voltage
24V
Drawbar Pull
43500lb
Fuel Capacity
80gal
Front Tire Size
14.00 x 24
Hydraulic System Fluid Capacity
54gal
Rear Tire Size
14.00 x 24
Axle Load - Front
102127lb
Axle Load - Rear
9290lb
Transmission
Number Of Forward / Reverse Speeds
5 / 3
Drive System
Powershift Transmission
Transmission Type
ZF WG 211
Brakes
Service Brake
Oil immersed (wet) disc
Parking Brake
Dry Disc on Drive Axle
