Hyster H50FT Diesel Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
8.4ft in
B
Overall Width
3.8ft in
C
Overall Height - Mast Lowered
7.12ft in
D
Wheelbase
5.33ft in
E
Ground Clearance
6.3in
F
Height To Top Of Overhead Guard
7.09ft in
G
Max Fork Height
10.81ft in
Turning Radius
7.06ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
10degrees
Max Fork Spread
43.27in
Lower Speed
83ft/min
Load Center
24.02in
Load Capacity
5000.09lb
Lift Speed
134ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
Yanmar 2.6L
Power
48hp
Torque
108lb ft
Displacement
162.3cu in
Torque Measured @
1400rpm
Fuel Type
Diesel
Operational
Operating Weight
8750.2lb
Tire Type
Pneumatic
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
7.4mph
