Hyundai 20D-7 Forklift
Units
Dimensions
Dimensions
A
Length To Fork Face
8.3ft in
B
Overall Width
3.81ft in
C
Overall Height - Mast Lowered
7.14ft in
D
Wheelbase
5.42ft in
E
Ground Clearance
4.49in
F
Height To Top Of Overhead Guard
7.09ft in
G
Max Fork Height
10.83ft in
Turning Radius
7.39ft in
Mast
H
Mast Tip Forward
6degrees
I
Mast Tip Rear
10degrees
Lower Speed
98.43ft/min
Load Capacity
4000lb
Load Center
24in
Lift Speed
110.24ft/min
Specifications
Engine
Number Of Cylinders
4
Engine Make
2334
Engine Model
V3300
Power
63.1hp
Displacement
202.5cu in
Fuel Type
Diesel
Operational
Operating Weight
7945.5lb
Tire Type
Pneumatic
Number Of Front Wheels
2
Number Of Rear Wheels
2
Max Speed
11.7mph
