Hyundai HSL600T Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.65ft in
B
Width Over Tires
4.8ft in
E
Ground Clearance
7.52in
C
Height To Top Of Cab
6.13ft in
D
Wheelbase
2.92ft in
F
Length W/O Bucket
8.71ft in
G
Clearance At Max Lift And Dump
7.49ft in
H
Reach At Max Lift And Dump
28in
Turning Radius From Center - Machine Rear
61.89in
Turning Radius From Center - Inc Bucket
72.6in
Specifications
Engine
Engine Make
2334
Engine Model
V1903E
Gross Power
43hp
Net Power
39hp
Power Measured @
2800rpm
Operational
Operational Weight
5350.7lb
Fuel Capacity
17gal
Hydraulic System Fluid Capacity
8.1gal
Max Speed
6.3mph
Tire Size
10.00x16.5
Loader
Operating Load Rating
1300lb
Tipping Angle
2700.7degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
16.6gal/min
Relief Valve Pressure
2400psi
