Hyundai HSL650-7 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.73ft in
B
Width Over Tires
4.98ft in
E
Ground Clearance
7.21in
C
Height To Top Of Cab
6.45ft in
D
Wheelbase
3.25ft in
F
Length W/O Bucket
8.62ft in
G
Clearance At Max Lift And Dump
7.35ft in
H
Reach At Max Lift And Dump
21.66in
Turning Radius From Center - Machine Rear
61.42in
Turning Radius From Center - Inc Bucket
76.19in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2334
Engine Model
V2203M
Gross Power
44.2hp
Net Power
42.6hp
Power Measured @
2500rpm
Displacement
134.3cu in
Operational
Operational Weight
5787lb
Fuel Capacity
16gal
Max Speed
7.3mph
Hydraulic System Fluid Capacity
10gal
Tire Size
10-16.5, 6PR
Loader
Operating Load Rating
1433lb
Tipping Angle
2538degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
18.4gal/min
Relief Valve Pressure
2538psi
