Hyundai HSL850-7 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
11.39ft in
B
Width Over Tires
6.01ft in
E
Ground Clearance
8.08in
C
Height To Top Of Cab
6.57ft in
D
Wheelbase
3.61ft in
F
Length W/O Bucket
9.32ft in
G
Clearance At Max Lift And Dump
7.91ft in
H
Reach At Max Lift And Dump
20.08in
Turning Radius From Center - Machine Rear
65.36in
Turning Radius From Center - Inc Bucket
81.89in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2334
Engine Model
V3300DI
Gross Power
68hp
Net Power
66hp
Power Measured @
2400rpm
Operational
Operational Weight
7253.3lb
Fuel Capacity
22gal
Hydraulic System Fluid Capacity
15gal
Max Speed
7.2mph
Tire Size
12-16.5 12PR
Loader
Operating Load Rating
1852lb
Tipping Angle
3715degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
17.7gal/min
Relief Valve Pressure
2538psi
