Hyundai R160LCD-7 Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
29.57ft in
Shipping Height Of Unit
9.72ft in
Max Cutting Height
28.68ft in
Max Loading Height
20.02ft in
Max Reach Along Ground
27.99ft in
Max Vertical Wall Digging Depth
18.57ft in
Max Digging Depth
18.57ft in
Boom/Stick Option (Hex) 1
16'9 (5100mm) Boom / 7'3(2200mm) Stick
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
29.5ft in
Max Cutting Height
29.11ft in
Shipping Height Of Unit
9.55ft in
Max Loading Height
20.48ft in
Max Reach Along Ground
29.11ft in
Max Vertical Wall Digging Depth
17.85ft in
Max Digging Depth
19.89ft in
Boom/Stick Option (Hex) 2
16'9 (5100mm) Boom / 8'6 (2600mm) Stick
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
29.5ft in
Max Cutting Height
29.43ft in
Max Loading Height
20.94ft in
Shipping Height Of Unit
10.14ft in
Max Reach Along Ground
30.52ft in
Max Vertical Wall Digging Depth
18.8ft in
Max Digging Depth
21.53ft in
Boom/Stick Option (Hex) 3
16'9 (5100mm) Boom / 10'2 (3100mm) Stick
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
29.43ft in
Shipping Height Of Unit
9.98ft in
Max Cutting Height
30.81ft in
Max Loading Height
21.92ft in
Max Reach Along Ground
28.22ft in
Max Digging Depth
17.92ft in
Max Vertical Wall Dig Depth
15.33ft in
Boom/Stick Option (Hex) 4
16\'9 (5100mm) Boom / 7\'3(2200mm) 2pc
Boom/Stick Option (Hex) 5
Shipping Length Of Unit
29.4ft in
Shipping Height Of Unit
10.01ft in
Max Cutting Height
31.5ft in
Max Loading Height
22.64ft in
Max Reach Along Ground
29.4ft in
Max Digging Depth
19.13ft in
Max Vertical Wall Dig Depth
16.51ft in
Boom/Stick Option (Hex) 5
16\'9 (5100mm) Boom / 8\'6 (2600mm) 2pc
Dimensions
Ground Clearance
1.51ft in
Height To Top Of Cab
9.57ft in
Width To Outside Of Tracks
8.5ft in
Length Of Track On Ground
10.47ft in
Tail Swing Radius
8.31ft in
Removal Counterweight Clearance
3.4ft in
Undercarriage
Track Gauge
6.53ft in
Shoe Size
23.63in
Ground Pressure
6.4psi
Max Travel Speed
3.48mph
Drawbar Pull
34600lb
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
49
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2251
Engine Model
S6S-DT
Gross Power
126hp
Net Power
116hp
Power Measured @
2100rpm
Max Torque
307lb ft
Displacement
305cu in
Aspiration
Turbocharged
Torque Measured @
1500rpm
Operational
Operating Weight
40565.1lb
Fuel Capacity
68.7gal
Cooling System Fluid Capacity
8gal
Hydraulic System Fluid Capacity
63.5gal
Operating Voltage
24V
Engine Oil Capacity
4.4gal
Swing Drive Fluid Capacity
1.4gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4690psi
Hydraulic Pump Flow Capacity
88.8gal/min
Swing Mechanism
Swing Speed
12.1rpm
Buckets
Reference Bucket Capacity
1yd3
Minimum Bucket Capacity
0.6yd3
Maximum Bucket Capacity
1.2yd3
