Hyundai R210LC-7 High Chassis Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
31.63ft in
C
Shipping Height Of Unit
10.9ft in
I
Max Cutting Height
30.62ft in
J
Max Loading Height
21.4ft in
K
Max Reach Along Ground
29.27ft in
L
Max Vertical Wall Digging Depth
16.7ft in
M
Max Digging Depth
18.48ft in
Boom/Stick Option (Hex) 1
18'8 (5680mm) Boom / 6'7 (2000mm) Stick
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
31.34ft in
I
Max Cutting Height
31.27ft in
C
Shipping Height Of Unit
10.57ft in
J
Max Loading Height
22.02ft in
K
Max Reach Along Ground
30.48ft in
L
Max Vertical Wall Digging Depth
18.15ft in
M
Max Digging Depth
19.72ft in
Boom/Stick Option (Hex) 2
18'8 (5680mm) Boom / 7'10 (2400mm) Stick
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
31.07ft in
I
Max Cutting Height
31.7ft in
J
Max Loading Height
22.51ft in
C
Shipping Height Of Unit
10.11ft in
K
Max Reach Along Ground
31.96ft in
L
Max Vertical Wall Digging Depth
19.46ft in
M
Max Digging Depth
21.49ft in
Boom/Stick Option (Hex) 3
18'8 (5680mm) Boom / 9'7 (2920mm) Stick
Boom/Stick Option (Hex) 4
A
Shipping Length Of Unit
31.37ft in
C
Shipping Height Of Unit
11.46ft in
I
Max Cutting Height
33.8ft in
J
Max Loading Height
24.55ft in
K
Max Reach Along Ground
35.21ft in
M
Max Digging Depth
24.71ft in
Boom/Stick Option (Hex) 4
18'8 (5680mm) Boom / 12'10 (3900mm) Stick
Max Vertical Wall Dig Depth
23.13ft in
Dimensions
E
Ground Clearance
2.17ft in
G
Height To Top Of Cab
10.18ft in
B
Width To Outside Of Tracks
11.14ft in
D
Length Of Track On Ground
11.98ft in
H
Tail Swing Radius
9.29ft in
Removal Counterweight Clearance
4.14ft in
Undercarriage
F
Track Gauge
9.17ft in
N
Shoe Size
23.63in
Number Of Carrier Rollers Per Side
2
Max Travel Speed
3.3mph
Ground Pressure
6.97psi
Number Of Track Rollers Per Side
9
Number Of Shoes Per Side
49
Drawbar Pull
47434.69lb
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
B5.9-C
Gross Power
150hp
Net Power
143hp
Power Measured @
1950rpm
Max Torque
453lb ft
Displacement
359cu in
Aspiration
Turbocharged and Charge air cooled
Torque Measured @
1500rpm
Operational
Operating Weight
51060lb
Fuel Capacity
89.9gal
Cooling System Fluid Capacity
9.3gal
Hydraulic System Fluid Capacity
76.7gal
Operating Voltage
24V
Engine Oil Capacity
6.4gal
Swing Drive Fluid Capacity
1.4gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4690psi
Hydraulic Pump Flow Capacity
116.3gal/min
Swing Mechanism
Swing Speed
12.5rpm
Buckets
Reference Bucket Capacity
1.3yd3
Minimum Bucket Capacity
0.7yd3
Maximum Bucket Capacity
1.8yd3
