JCB 411HT High Lift Wheel Loader
Units
Dimensions
Bucket
G
Dump Clearance At Max Raise
8.73ft in
Breakout Force
16456.02lb
Bucket Capacity - Heaped
1.57yd3
Bucket Capacity - Struck
1.31yd3
Bucket Width
7.39ft in
Dimensions
E
Ground Clearance
1.35ft in
A
Length With Bucket On Ground
19.9ft in
C
Height To Top Of Cab
10.1ft in
D
Wheelbase
8.86ft in
F
Hinge Pin - Max Height
11.06ft in
H
Reach At Max Lift And Dump
3.51ft in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2257
Net Power
85.3hp
Gross Power
92hp
Power Measured @
2200rpm
Max Torque
286.2lb ft
Displacement
268.6cu in
Torque Measured @
1400rpm
Aspiration
turbocharged
Operational
Operating Weight
19122.9lb
Fuel Capacity
33.1gal
Hydraulic System Fluid Capacity
29.1gal
Engine Oil Fluid Capacity
3.1gal
Cooling System Fluid Capacity
6.1gal
Transmission Fluid Capacity
7.2gal
Front Axle/Diff Fluid Capacity
6.7gal
Rear Axle/Diff Fluid Capacity
6.7gal
Static Tipping Weight
11834.5lb
Turning Radius
17.8ft in
Operating Voltage
24V
Alternator Supplied Amperage
55amps
Rear Axle Oscillation
12.5degrees
Tire Size
Michelin 15.5R25 XHA (L3)
Transmission
Transmission Type
smooth shift powershift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
23.4mph
Max Speed - Reverse
17.1mph
Hydraulic System
Relief Valve Setting
3190psi
Pump Flow Capacity
13.3gal/min
Raise Time
5sec
Dump Time
1.1sec
Lower Time
3.7sec
Pump Type
double gear pump
