JCB 456ZX High Lift Integrated Tool Carrier
Units
Dimensions
Dimensions
A
Length W/ Bucket On Ground
27.96ft in
B
Width Over Tires
8.87ft in
C
Height To Top Of Cab
11.06ft in
D
Wheelbase
10.83ft in
E
Ground Clearance
1.55ft in
F
Hinge Pin Max Height
15.35ft in
G
Dump Clearance At Max Lift
11.35ft in
K
Max Lift Height
14.99ft in
I
Fork Tine Length
4.01ft in
Bucket
GP
Reach At Max Height And Dump
3.82ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
6CT 8.3C
Gross Power
216hp
Net Power
197hp
Power Measured @
2200rpm
Max Torque
733.2lb ft
Torque Measured @
1400rpm
Displacement
506.5cu in
Aspiration
turbocharged
Operational
Operating Weight
42668lb
Fuel Capacity
84.6gal
Cooling System Fluid Capacity
10.6gal
Engine Oil Capacity
5gal
Transmission Fluid Capacity
9gal
Front Diff Fluid Capacity
18.3gal
Rear Diff Fluid Capacity
13.5gal
Hydraulic System Fluid Capacity
56.8gal
Turning Radius
22.3ft in
Operating Voltage
24V
Alternator Supplied Amperage
70amps
Rear Axle Oscillation
25degrees
Static Tipping Load - Bucket
25216.5lb
Static Tipping Load - Forks
19581.5lb
Tire Size
23.5x25x20 ply L2
Transmission
Transmission Type
smooth shift powershift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed Forward
23.3mph
Max Speed Reverse
15.2mph
Hydraulic System
Pump Type
twin variable displacement piston pump
Relief Valve Setting
3625psi
Pump Flow Capacity
85.4gal/min
Raise Time
5.8sec
Dump Time
1.2sec
Lower Time
4.1sec
Bucket
Breakout Force
31922.9lb
Bucket Capacity - Heaped
4.4yd3
Bucket Capacity - Struck
3.9yd3
