JCB 560-80 AGRI Telescopic Forklift
Units
Dimensions
Dimensions
E
Ground Clearance
1.32ft in
B
Width Over Tires
8.34ft in
C
Overall Height
8.5ft in
D
Wheelbase
9.03ft in
Weight
23214.68lb
Lift Capacity To Full Height
6613.87lb
Lift
F
Max Lift Height
25.92ft in
G
Max Forward Reach
14.47ft in
Max Lift Capacity
13227.74lb
Specifications
Electrical System
Battery Capacity
220 Ah
Voltage
12 VV
Engine
Engine Oil Service Interval Hours
500
Emissions Level
T4F / Stage IV
Number Of Cylinders
4
Engine Make
JCB
Gross Power
144.9hp
Power Measured @
2200rpm
Max Torque
413.1lb ft
Torque Measured @
1500rpm
Displacement
293cu in
Bore
4.2in
Stroke
5.4in
Aspiration
TCA
Capacities
Fuel Tank
38.6gal
Hydraulic Tank
29.6gal
Diesel Exhaust Fluid (Def) Tank
5.5gal
Engine Oil
3.7gal
Engine Coolant
6.1gal
Transmission
Lift Capacity At Full Reach
3858.1lb
Hydraulic System
Extend
8.3sec
Retract
5.9sec
Bucket Crowd
3sec
Max Operating Pressure
260 bar
Hydraulic
Pump Type
Variable
Hydraulic System
Raise Time
7.4sec
Dump Time
2.8sec
Lower Time
8.3sec
