JCB 8020 CTS Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
Maximum Height To Dipper Nose Pivot Pin
10.48ft in
Minimum Front Swing Radius (No Offset)
5.7ft in
Maximum Digging Depth – Dozer Up
8.22ft in
Maximum Vertical Wallcut Depth
7.18ft in
Max Digging Height
12.11ft in
Max Digging Reach
14.14ft in
Max.Dumping Height
9.12ft in
Maximum Digging Depth – Dozer Down
8.6ft in
Dimensions
E
Ground Clearance
0.49ft in
F
Track Gauge
3.65ft in
Width Over Tracks
3.29ft in
Cab Width
38.35in
Height Over Cab
7.73ft in
Overall Width Of Superstructure
3.27ft in
Undercarriage Overall Length
5.66ft in
Cab Length
309.35gal
Transport Length
141.74in
Undercarriage
Number Of Bottom Rollers Per Side
4
Track Tension
Grease
Specifications
Engine
Fuel
Diesel
Starter Motor
1.48 hp
Engine Model
403D-11
Gross Power
19.7hp
Cooling System
Water cooled
Net Power
19hp
Displacement
69.1cu in
Gross Torque
49.3lb ft
Max Torque
47.4lb ft
Alternator
40amps
Capacities
Fuel Tank
6.3gal
Hydraulic Tank
6.7gal
Hydraulic System
7.4gal
Engine Oil
1.1gal
Engine Coolant
1.4gal
Operational
Operating Weight
4557lb
Performance
Gradeability
35%
Blade
Approach Angle
25degrees
Hydraulic System
Nominal Output
14.7gal/min
Blade
Maximum Height
1.1ft in
Hydraulic System
Slew Main Relief
160 bar
Excavator/Track Main Relief
230 bar
Blade
Dig Depth (Below Ground)
0.7ft in
Reach In Front Of Tracks
1.3ft in
Hydraulic System
Hydraulic Motor (Travel)
Piston
Auxiliary Hydraulic Flow
6.9gal/min
Pump Type
1 Variable (2 Ports) or 1 Gear
Blade
Blade Height
6.9in
Width
3.3ft in
