JCB 803 Super Midi Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
14.23ft in
C
Shipping Height Of Unit
7.98ft in
I
Max Cutting Height
14.31ft in
J
Max Loading Height
10.51ft in
K
Max Reach Along Ground
15.6ft in
M
Max Digging Depth
9.9ft in
Boom/Stick Option (Hex) 1
boom w/ arm 1400mm
Dimensions
B
Width To Outside Of Tracks
4.76ft in
D
Length Of Track On Ground
5.21ft in
G
Height To Top Of Cab
7.98ft in
H
Tail Swing Radius
4.76ft in
Undercarriage
N
Shoe Size
9.06in
Number Of Track Rollers Per Side
4
Ground Pressure
4.7psi
Max Travel Speed
2.24mph
Specifications
Engine
Engine Model
403-15
Gross Power
27.8hp
Net Power
26.6hp
Max Torque
67.9lb ft
Operational
Operating Weight
14793.1lb
Fuel Capacity
12.7gal
Operating Voltage
12V
Hydraulic System Fluid Capacity
18.5gal
Engine Oil Capacity
1.4gal
Alternator Supplied Amperage
55amps
Hydraulic System Relief Valve Pressure
3002.3psi
Hydraulic Pump Flow Capacity
7.7gal/min
Swing Mechanism
Swing Speed
9.5rpm
