JCB 8040ZTS Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
16.75ft in
I
Max Cutting Height
17.18ft in
C
Shipping Height Of Unit
8.42ft in
J
Max Loading Height
12.58ft in
K
Max Reach Along Ground
18.43ft in
L
Max Vertical Wall Digging Depth
7.25ft in
M
Max Digging Depth
10.92ft in
Boom/Stick Option (Hex) 1
Arm Length 5ft.0in.(1525mm )
Dimensions
B
Width To Outside Of Tracks
6.5ft in
D
Length Of Track On Ground
6.08ft in
E
Ground Clearance
1.12ft in
G
Height To Top Of Cab
8.42ft in
H
Tail Swing Radius
3.25ft in
Removal Counterweight Clearance
2.25ft in
Undercarriage
N
Shoe Size
16in
F
Track Gauge
5.17ft in
Drawbar Pull
10858.3lb
Max Travel Speed
2.42mph
Number Of Track Rollers Per Side
4
Ground Pressure
4.12psi
Specifications
Engine
Engine Make
2351
Engine Model
404-22c
Gross Power
46.4hp
Net Power
45hp
Power Measured @
2200rpm
Displacement
2.3cu in
Max Torque
101.3lb ft
Torque Measured @
1600rpm
Operational
Operating Weight
9480lb
Fuel Capacity
18gal
Cooling System Fluid Capacity
3.6gal
Hydraulic System Fluid Capacity
25.9gal
Engine Oil Capacity
3.8gal
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Hydraulic System Relief Valve Pressure
3191psi
Hydraulic Pump Flow Capacity
23.8gal/min
Swing Mechanism
Swing Speed
10rpm
